GWT40H65FB STGWT40H65FB IGBT 80A 650V TO-3P
GWT40H65FB is a type of IGBT (Insulated Gate Bipolar Transistor) designed for high power applications, such as in motor control, UPS inverters, and industrial equipment.
anufacturer Part Number: STGWT40H65FB
Brand: STMicroelectronics
DateCode: 14+ROHS
Package / Case: TO3P
Category: Discrete Semiconductor
Voltage - Collector Emitter Breakdown (Max): 650V
Vce(on) (Max) @ Vge, Ic:2.3V @ 15V, 80A
Current - Collector Pulsed (Icm): 160A
Current - Collector (Ic) (Max): 80A
Test Condition: 400V, 40A, 5 Ohm, 15V
Td (on/off) @ 25°C: 40ns/142ns
Switching Energy: 498mJ (on), 363mJ (off)
Supplier Device Package: TO-3P
Series:-
Power - Max: 283W
Other Names: 497-14230-5
Operating Temperature: -55°C ~ 175°C (TJ)
Mounting Type: Through Hole
Moisture Sensitivity Level (MSL): 1 (Unlimited)
Lead Free Status / RoHS Status: Lead free / RoHS Compliant
Input Type: Standard
IGBT Type: Trench Field Stop
Gate Charge: 210nC
