Object detection is indicated through the occurrence of a low state at the output (black wire) and the switching on of the red led. The advantage of the sensor is also protection against reverse power connection.
Supply voltage: 5 V
Consumption of current: below 100 mA
The measuring range is adjustable: from 5 to 80 cm
Knob of range’s regulation – rotary potentiometer
Output signal: digital (low state in the case of object detection, otherwise high)
The led indicating the detection of the object
Response time: below 2 MS
Protection against reverse polarity
Operating temperature: -25 °C to +55 °C
Diameter: 18 mm
Sensor length: 50 mm
