Model: KSV05A
voltage: 3 to 4 V DC
Leakage: <3mmHg/min
Max pressure: 300mmHg
Type: Normal open
Rated life cycle: 30000cycles @ ON 7s and OFF 5s
Resistance: 23+- 10% Ohm
weight: 10g
Size: 10 * 12 * 20 mm
normally open type solenoid valve / exhaust valve / exhaust valve, low price
DESCRIPTION
Model series KSV offers great performance in a very economical design. This product is best suited for OEM applications where the valve performance is acceptable and where low component cost is necessary.The valve plunger and spring are fabricated from steel and therefore the valve is limited to use with air and other inert gases.Product uses are on medical equipment such as venting a cuff on automatic blood pressure measurement equipment, appliance applications and a range of industrial low pressure pneumatic control applications.
